TouchMonitor TMR7 comes in a variety of incarnations. We have taylor-made completely configured models suited for specific applications, but if none of those fit your needs, you can custom build a TouchMonitor.

Form Factor

Most customers prefer their TouchMonitor in the traditional table-top form factor, but we have other form factors to choose from.

Our so-called OEM version - the "raw" version with no enclosure - is relevant if you need to mount the TouchMonitor in your own environment. Also, the OEM version can be expanded with a rack-mount kit to fit any standard 19" rack in a machine room or OB van.

TMR7
TMR7OEM


Hardware

In contrast to the hardware I/O options of the TouchMonitor TM7 and TM9 devices, the connections of the TMR7 are already permanently implemented.

Digital XLR-3p

  • 4 digital inputs balanced (2 x AES3 In, XLR-3p-f)
  • 4 digital outputs (2 x AES3 Out, XLR-3p-m)

Rack-Mount

TMR7 can be rack-mounted, using the TMR7OEM with different 19"/3U mounting adapters. You would also need a PSU.



TM7-MA3U

(3U mounting adapter)
Mounting kit including a 19“/3U/42HP rackmount panel (half-19“/3U) and fastening material for mounting TMR7-Mount or TMR7OEM into standard 19“ sub-racks (e. g. RTW 1647831).

TM7-MAVID

(VID mounting adapter)
Mounting kit including a half-19“/3U plug-in panel and fastening material for mounting TMR7OEM into standard 19“ rack-mount cabinets for video racks.

1647831

(19"/3U rack frame)
Standard 19“ sub-rack for mounting up to 2 TM7-Mount or 20700OEM in conjunction with TM7-MA3U mounting kit. Includes a blank panel to cover unused space.

Accessories

1178-R - Wide Range Power Supply

Wide range 100 - 240 V AC/24 V DC 2.71 A, table-top power supply with corresponding power cable for different power supply systems
