RTW Products
Compared Side by Side
Find the Perfect RTW Solution for Your Workflow
- TMxCore
- TouchMonitor 5
- TouchControl 5
- TouchMonitor TM7 / TM9
| Feature | TouchControl 5 | TouchMonitor 5 | TMxCore | TM7 / TM9 |
|---|---|---|---|---|
| Audio Inputs & Outputs | ||||
Dante RJ-45 | ✅ | ✅ | ✅ | ✅ |
Ravenna RJ-45 ST 2110, AES67, NMOS | ✅ | ✅ | ✅ | ✅ |
16 AES3 I/O 2 x Sub-D 25 | - | - | ✅ | ✅ |
8 AES3 I/O + 8 Analog Inputs 2 x Sub-D 25 | - | - | - | ✅ |
16 AES3iD I/O 8 x BNC | - | - | - | ✅ |
3G-SDI | - | - | - | ✅ |
XLR In, MIC, Line Out | ✅ | - | - | - |
Max Audio Channels Depending on I/O | 32 | 16 | 32 | 32 (SW20001) 48 (In case of SDI) |
| Network | ||||
AoIP Redundancy | - | - | ✅ | ✅ |
Dedicated Network Control Port | - | - | 2,5 Gbit | 10/100 Mbit |
Remote Configuration WebApp with presets editor, settings etc. | ✅ | ✅ | ✅ | - |
Open Sound Control (OSC) | ✅ | ✅ | ✅ | - |
| Other | ||||
GPIO RJ-12 | - | - | ✅ | ✅ |
Display Output | - | - | DisplayPort 4K: 3840 × 2160 | Analog VGA TM7: 800 x 480 TM9: 1024 x 600 |
USB | - | - | ✅ | ✅ |
PSU | - | - | ✅ | ✅ |
| Features | ||||
Network Display | Simple SW32030 | Simple SW22030 | ✅ | - |
Network Display Connections Concurrent Browser Sessions | 3 | 2 | 3 per screen up to 12 views | - |
Multiple Screens | - | - | Screen 1: SW23030 Screen 2: SW23031 Screen 3: SW23032 | - |
Views per preset | 3 | 2 | 3 per screen Up to 12 views | - |
Formats: Surround | ✅ | ✅ | ✅ | SW20001 |
Formats: Immersive | ✅ | ✅ | ✅ | SW20001 |
Formats: MultiChannel | ✅ | ✅ | ✅ | SW20001 |
Loudness | ✅ | ✅ | ✅ | SW20002 |
Extended Scale Selection Zoom, Nordic, British, DIN, DIG, ARD+9, et al. | ✅ | ✅ | ✅ | SW20006 |
Extended Scale Features Scale marker, DC filter, Spot Correlator, Integration Time | ✅ | ✅ | ✅ | SW20006 |
Delay Compensation | ✅ | ✅ | ✅ | - |
| Applications | ||||
Metering | ✅ | ✅ | ✅ | ✅ (Audio Groups) |
Monitoring | ✅ | - | - | - |
Leveling | ✅ | - | - | - |
Talkback | ✅ | - | - | - |
| Classic Instruments | ||||
PPM | ✅ | ✅ | ✅ | ✅ |
Moving Coil | ✅ | ✅ | ✅ | SW20006 |
Stereo Correlator | ✅ | ✅ | ✅ | ✅ |
VectorScope | ✅ | ✅ | ✅ | SW20006 |
Realtime Analyzer | ✅ | ✅ | ✅ | SW20003 |
Chart | ✅ | ✅ | ✅ | SW20002 + SW20014 |
Summation | ✅ | ✅ | ✅ | SW20002 |
Numerical | ✅ | ✅ | ✅ | SW20002 |
Numerical, Dialog Gated | ✅ | ✅ | ✅ | - |
Loudness Range (LRA) | ✅ | ✅ | ✅ | SW20002 |
Loudness Range (LRA), Dialog Gated | ✅ | ✅ | ✅ | - |
Ratio Instrument | ✅ | ✅ | ✅ | - |
| Immersive Instruments | ||||
LFE Bleed | ✅ | ✅ | ✅ | - |
Immersive Sound Analyzer | - | - | SW23010 | SW20001 + SW20002 + SW20004 + SW20015 |
Matrix Correlator | - | - | SW23010 | - |
Multi Correlator | - | - | SW23010 | SW20001 + SW20006 |
Polar Scope | - | - | SW23010 | - |
| Dialog Intelligibility | ||||
Dialog Intelligibility Fraunhofer IDMT Algorithm | - | - | SW23020 | - |
Ratio Instrument | ✅ | ✅ | ✅ | - |
Dialog Detector | ✅ | ✅ | ✅ | - |
LDR Loudness-to-Dialog-Ratio | ✅ | ✅ | ✅ | - |
BDR Background-to-Dialog-Ratio | ✅ | ✅ | ✅ | - |
| Tools | ||||
Clock | - | - | ✅ | - |
Actions Able to control other devices Open Sound Control (OSC), HTTP Request | ✅ | ✅ | ✅ | - |
Open Sound Control (OSC) Listener Device can be controlled by other devices | ✅ | ✅ | ✅ | - |
Label | ✅ | ✅ | ✅ | - |
| Monitoring Instruments | ||||
Speaker Control Volume, Solo, Cut, Phase | ✅ | - | - | - |
Monitor Control Features Dim, Mute, Mono, Phones, Level Recall, Downmix | ✅ | - | - | - |
Speaker Calibration Test Tone Generator, delay, polarity, level, 8 band EQ | ✅ | - | - | - |
Talkback | ✅ | - | - | - |
Calibrated Room SPL | ✅ | - | - | - |
Input Trim | ✅ | - | - | - |
Input/Output Selection | ✅ | - | - | - |
| Leveling Instruments | ||||
Fader | ✅ | - | - | - |
| Available only on Classic TM | ||||
Radar | - | - | - | SW20002 + SW20005 |
Blitz | - | - | - | SW20013 |
SSA (now part of ISA) | - | - | - | SW20001 + SW20002 + SW20004 |
Logging Data Server | - | - | - | SW20002 + SW20014 |
Time Code Reader | - | - | - | SW20008 (SW20002 for recalculation) |
